HM1 Series Moulded Case Circuit Breaker

Phone : +86 18958818822

WeChat : +86 18958818822

Whatsapp : +86 18958818822

Email : 303272547@qq.com

Product Description

1. Application

HM1 series moulded case circuit breaker is one of products developed and manufactured by adopting international advanced technology. It is supplied with rated insulating voltage 500 and 800V and used for the circuit of AC 50/60Hz, rated operating voltage AC 400V (or below), rated operating current up to 1600A for infrequently changing over and starting of the motors. The products conforms to IEC60947-2 standard.

2. Main Technical Specification

Note: 6A without thermal protection

The N-pole of four-poles breaker is sited at the right side of the product has four types:

Type	Rated current(A)	Pole	Rated insulating voltage(V)	Rated operating voltage(V)	Arcing- over distance (mm)	Ultimate short circuit breaking capacity (kA)	Service short circuit breaking capacity (kA)	Operation performance		Utilization cate- gory
Type	Rated current(A)	Pole	Rated insulating voltage(V)	Rated operating voltage(V)	Arcing- over distance (mm)	Ultimate short circuit breaking capacity (kA)	Service short circuit breaking capacity (kA)	Load	Unload	Utilization cate- gory
HM1-63L	(6),10,1620,25,3240,50,63	3,4	500V		0	25	18
HM1-63M	(6),10,1620,25,3240,50,63	3,4	500V		0	50	35	1500	8500
HM1-125L	(10),16,20,2532,40,50,6380,100,125				0(<50)	35	22	1500	8500
HM1-125M	(10),16,20,2532,40,50,6380,100,125	1,2,			0(<50)	50	35
HM1-250L	125,150,160,175,180,200,225,250	3,4			<50	35	22	1000	7000
HM1-250M	125,150,160,175,180,200,225,250				<50	50	35	1000	7000
HM1-400L	225,250,315		800V	400V	<50	50	35			A
HM1-40OM	350,400	1,3,4			<100	65	42
HM1-630L	400,500,600	1,3,4			<100	50	35
HM1-630M	400,500,600				<100	65	42	1000	4000
HM1-800M	630,700,800				<100	75	50
HM1-1250M	1000,1250	3,4			<100	100	65
HM1-1600M	1600				<100	150	80

Type A: Without current trip-release on N pole which making all the time, not closing and opening with the other three poles.

Type B: Without current trip-release on N pole which closing and opening with the other poles.

Type C: With current trip-release which closing and opening with the other three poles.

Type D: With current trip release which making all the time not closing and opening with the other three poles.

1. Protection Characteristic

The thermodynamic release of a circuit breaker provides the feature of inverse time-delay, while the magnetic release is the instantaneous operation as shown on table 2(distribution circuit breaker) and table 3(motor protection circuit breaker.

Rated current of release (A)	Thermodynamic release( ambient temperature 麗當*c)		Operating current of magnetic release (A)
Rated current of release (A)	1.05ln(cold state)Inoperative time(h)	1.30ln(heat state) Operative time(h)	Operating current of magnetic release (A)
10 < In < 63	> 1	< 1	10ln±20%
63 < In < 100	> 2	<2	10ln±20%
100 < In < 800	> 2	<2	5ln±20%10ln±20%

Rated current of release (A)	Thermodynamic release ( ambient temperature辭罢。。)				Operating current of magnetic release (A)
	1.0ln(cold state) non-trip time(h)	1.20ln(heat state) trip time (h)	1.50ln(heat state) trip time (m)	7.2ln(cold state) trip time(s)
10 < In < 250	> 2	<2	< 4< 8	4 < t < 10	12ln±20%
250 < In < 630				6 < t < 20

1. Accessories of Circuit Breaker

4.1 The external accessories of the breaker

• Electromagnetic operation device and Motor-driven operation device

1) Wiring diagram of type CDM electromagnetic operation device(fitting HM 1-63,100,250) see the following drawing (wiring diagram of the external accessories of the breaker in the dotted

Code description: SB1, SB2 stand for push button.(provided by users themselves) Number "2"、^ll3" stand for number of wiring terminals.

Voltage rating: AC50/60Hz 230V 400V, DC 220V 2) Wiring diagram of type CD Electromagnetic operation device and motor-driven operation device (fittingHM 1-400、630、800) see belows (wiring diagram of the external accessories of the breaker in the dotted frame)

Code description: SB1, SB2 stand for push button, (provided by users themselves)

^UX" stands for line connection terminals

Voltage rating: AC50/60Hz 230V 400V, DC220V
