1. Application

HM9 series MCCB is suitable for industrial or commercial power and lighting with AC50/ 60Hz, rated working voltage up to AC600V/DC250V, rated current up to 630A. It's a kind of economical breaker with the characters of stable and reliable function, beautiful appearance, small size and long life. It can be used for conversion of line and infrequently starting motor. It can also be attached to install the accessories which have protection function for avoiding lossvoltage, undervoltage. The product can connect line with front board and back board, it also can be equipped with hand-operating apparatus or motor-operating apparatus to control in a remote distance.

2. Specification

The rated insulation voltage for this series of circuit breaker is 690V, the rated operating voltage is 600V, the rated frequency is 50/60Hz, the other rated values for the main circuit.

3. Outline and Installation Dimensions (mm)
