The mechanism is used with moulded case circuit breaker to operate the draw-out panel. Power distribution panel and supply box outside the panel by turning the handle ,and to ensure the door of panel would not be openned when the breaker being on.

4.2 Release pattern and accessories code

When the operation voltage is 85%~110% of the rated voltage, the under-voltage release should make the breaker close.

In case of the operation voltage less than 35% of the rated voltage, the under-voltage should prevent the breaker from closing.

Note: Only the under-voltage release should be energized in advance, the breaker could be recramped and turned-on, otherwise the breaker will be damaged.
